They may have gotten their start in control rooms along with production switchers, but have evolved helping engineers check signal distribution paths from their routers and are now being used as a high-quality multi-signal live preview and recording device. With the ability to display multiple video sources on a single display monitor, multiviewers have changed the way production and broadcast control rooms are designed and implemented. Audio Monitoring OutputĪudio from any channel can be monitored via HD-SDI, HDMI, or analog audio output.Multiviewers have become a necessity in today’s AV industry. If not used as a clock display, this feature can be used as a count up/down timer, or remaining time counter. Two clocks can be displayed, in analog or digital format.
Time DisplayĬorrect clock time is ensured by SNTP server sync. Add two logos and one background per output, as required. Register up to eight logos and four background images.
Titles: Identify each source channel with a title.Tally: Choose from frame tally or marker tally display.Tally Display/Title Display/Timecode Display For each source signal, use Layout Manager to customize displays for positions, the number of channels shown, and the display groups. Monitor audio levels of up to 16 channels of HD/SD-SDI embedded audio. Standard front control panel enables layout and channel switching, local control settings, as well as remote operation. (Video is saved as still-image sequence files.) Front Control Panel Simply enter triggers to prepare for image capture. Take streaming a step further by capturing the video. The streaming video can be used for additional local computer display or for remote monitoring. In addition to computer-based layout management, you can also stream video from the viewer over Ethernet. Saved layouts can be applied directly from the front panel control. Store up to 16 layout patterns on the viewer. Customize the layout on a computer by registering or changing layout patterns, adjusting title display, and configuring other settings as needed.
FOR A MULTIVIEWER WINDOWS
Includes a Windows application for managing the layout. Sources can be displayed on one or two (option) screens, with HDMI and SDI interfaces available for both screens to support HD monitoring. The viewer accepts an array of formats and frame rates including NTSC, PAL, 1080/59.94i, 1080/23.98PsF and 1080/50i. Supports mixed signals as required, from HD-SDI, SD-SDI, or analog composite sources. Full-featured yet economical, the unit offers a customizable window layout and displays audio levels, titles, and timers, etc. The MV-1620HS is a compact (1RU) multi-viewer that accepts up to 16 channels of mixed HD/SD-SDI or analog composite signals for monitoring on one or two (option) screens.
